MsFlexGrid ActiveX does not show in AutoCAD

I registered the the msflxgrd.ocx and i could add the flexgrid in the opendcl studio.
When i load the project in AutoCAD and call the dcl_form_show it shows the dialog without the flexgrid.
Why is that? Any idea?

See screenshots.

I use:
Windows 10 x64
AutoCAD 2016 x64
OpenDCL 8.1.4.2

Joseph,

Can you attach a sample .DCL and .LSP file to show what you are doing.

Regards,


added:
For interest : Where did you get the x64 .DLL ?

Here is attached the dcl and lsp file.

What x64 DLL you mean?
I copied the msflxgrd.ocx from c:\windows\system32 to my c:\temp folder and used the following command to register it: regsvr32 "C:\Temp\msflxgrd.ocx" and i could add the flexgrid in opendcl but in autocad does not show the flexgrid.

Hi Joseph

a) what is "msflxgrd.ocx"? Where to find information about it?

b) Have you solved the problem? Maybe the file is not found by the software - c:\temp is usually not a common directory instead of %temp% and others
